■ Bleeding the Fuel System
The fuel system is to be bled whenever the tractor
has run out of fuel or when filters, pipes or other
components have been replaced.
1. Fill the tank with fuel.
2. Open Fuel filter cock.
3. Turn the key “ON” position for a while.
4. Start the engine and allow it to run for a while.
5. Stop the engine.
6. The bleeding of the system is now finished
FAN BELT
Ch k h f b l i l l d dj if i d
Ch
ec
k
t
h
e
f
an
b
e
l
t tens
i
on regu
l
ar
l
y an
d
a
dj
ust
if
requ
i
re
d
.
The correct tension is if the center of the belt is pushed.
With a finger it moves in approx. 10 to 12 mm
(0.4 to 0.5 in) under 10Kgf(22 lbf)[98N] as shown in the picture.
To adjust the fan belt loosen the top bolt on the alternator Move
CHECKING HOSES AND CLAMPS
10 to 12 mm (0.4 to 0.5 in) under
10Kgf(22 lbf)[98N]
To
adjust
the
fan
belt
loosen
the
top
bolt
on
the
alternator
,
Move
the alternator to the desired position and tighten the bolt.
Also ensure that the bolts at the bottom of the alternator are tight.
The fuel lines, radiator hoses, hydraulic and rubber hoses are consumables, which deteriorate by age
and use. Check them regularly and replace if faulty.
■ Checking the Fuel Hoses
1 Park tractor on level surface
1
.
Park
tractor
on
level
surface
2. Shutoff engine. Allow engine to cool enough.
3. Open the hood.
4. Check the fuel hoses for damage and leakage
5. Replace if required.
69
5.
Replace
if
required.
6. Tighten Clamps
