■ Changing Transmission Oil and Filter and Cleaning Strainer
1. Park tractor on level surface
2.
Lower the implements and shutoff engine.
2.
Lower
the
implements
and
shutoff
engine.
3. Remove the drain plug at the bottom of the
transmission case (and drain plug at the side of mid
PTO case, if mid PTO kit is assembled).
4. Drain the oil completely into container.
5
Loosen the hose clamp and detach the hose from the
5
.
Loosen
the
hose
clamp
and
detach
the
hose
from
the
strainer.
6. Remove the bolt and remove the strainer.
7. Clean the strainer
8. Reinstall the strainer, bolt and hose
Drain plug of MID PTO
Drain plug
of transmission case
Drain
plug
of
transmission
case
9. Remove the HST filter at the front of the HST
unit with filter wrench.
10. Smear lightly the rubber seal on the new filter
ith il t
w
ith
o
il
t
o ensure.
11.Tighten the filter until the seal contacts the
base and then turn it another 2/3 turn to
tighten it.
12 Remove the transmission oil cap at the top of
HST filter
12
.
Remove
the
transmission
oil
cap
at
the
top
of
hydraulic cylinder case.
13. Fill the transmission oil to the correct level on
the sight window.
14. After fillin
g,
install the ca
p
.
72
g, p
15. Run engine for a few minutes and stop it.
16. Check the oil level. Add if required.
