Mains connection
Connection as a plug-L1-L2-L3-N PE lockable (removable).
The electrical conjunction to the network is made with these connections.
Connecting digital outputs
Connector M4
PIN
DESCRIPTION
13
Digital OUT
Relay 5 - OPTIONAL
14
Digital OUT
Relay 5 - OPTIONAL
15
Digital OUT
Relay 4 – Alarm for external devices
16
Digital OUT
Relay 4 – Alarm for external devices
17
Digital OUT
Relay 3 – Cut-out temperature
18
Digital OUT
Relay 3 – Cut-out temperature
19
Digital OUT
Relay 2 – Ready signal for external devices
20
Digital OUT
Relay 2 – Ready signal for external devices
21
Digital OUT
Relay 1 - Filler
22
Digital OUT
Relay 1 - Filler
Connecting digital inputs
Connector M8
PIN
DESCRIPTION
31
Digital Input
OP24Vdc rectified
32
Digital Input
ID5 Glue level sensor
33
Digital Input
ID4 No used now
34
Digital Input
ID3 No used now
35
Digital Input
ID2 Digital standby (Digital signal from mother machine)
36
Digital Input
ID1 Digital start (Digital signal from mother machine)
37
Digital Input
GND Opto Common Input ID (OP24VDC rectified)
