40
Fuses
The external heaters are connected to the board via plug connections.
Each channel is individually protected. For outlets and fuses, please refer to the table below.
Main fuses
Fuse
L1
F1
L2
F2
L3
F3
24 Volt control circuit
F4
Channel
Fuse
2 Channel Board 1
Hose 1
F2
Head 1
F4
Hose 2
F1
Head 2
F3
2 Channel Board 2
Hose 3
F2
Head 3
F4
Hose 4
F1
Head 4
F3
2 Channel Board 3
Hose 5
F2
Head 5
F4
Hose 6
F1
Head 6
F3
2 Channel Board 4
Hose 7
F2
Head 7
F4
Hose 8
F1
Head 8
F3
Internal heating tank board
Tank 1
TK F1
Manifold
PTK F2
Pump connection
The glue pump is connected to the board
Intake plug for pump: P
Thermostat and fuse
The system has an over-temperature shutdown feature with a thermostat.
This safety circuit is connected to the board.
Intake plug for thermostat: Thermostats
