UES perfectMelt - Pin Assignment (2 Channel Board)

UES AG · Breuershofstr. 48 · 47807 Krefeld · Germany
Tel.: 0049-2151-72950 · Fax: 0049-2151-729578 · info@ues-ag.net · www.ues-ag.net
53
Pin assignment (2 channel board)
Connector M1
PIN
DESCRIPTION
Ne
Power supply
NEUTRAL
T
Power supply
T Phase
R
Power supply
R Phase
Connector M2
PIN
DESCRIPTION
R
Power supply
R Phase
T
Power supply
T Phase
NE
Power supply
NEUTRAL
Connector M3
Connector CN1
PIN
DESCRIPTION
1
UES Connect
Out gun A
2
UES Connect
NEUTRAL (for out gun A)
3
UES Connect
PT100 gun A
4
UES Connect
NEUTRAL (for out hose A)
5
UES Connect
GND (for PT100 gun A)
6
UES Connect
Out hose A
7
UES Connect
GROUND
8
UES Connect
PT100 hose A
9
UES Connect
GND (for PT100 hose A)
10
UES Connect
Not connected
11
UES Connect
Out electrovalve 1+
12
UES Connect
Out electrovalve 1-
PIN
DESCRIPTION
E1-
Out
Electrovalve gun 1-
E1+
Out
Electrovalve gun 1+
E2-
Out
Electrovalve gun 2-
E2+
Out
Electrovalve gun 2+
