UES perfectMelt - Technical Data

UES AG · Breuershofstr. 48 · 47807 Krefeld · Germany
Tel.: 0049-2151-72950 · Fax: 0049-2151-729578 · info@ues-ag.net · www.ues-ag.net
41
Technical data
perfectMelt 4kg / 8kg
perfectMelt 14kg
Weight (kg) ca.
48 / 50
55
Housing protection type
IP 53 dust proof control box
Ambient temperature
5 °C – 45 °C
5 °C – 45 °C
Glue pump(s) 1
Pistons
Pistons
Pressure relief when the
pressure drops
As standard 2
As standard 2
Min. air pressure storage
4 bar
4 bar
Working area pump
0.5 bar - 4.5 bar
0.5 bar - 4.5 bar
Tank size ca.
4 l / 8l
14 l
Melting power
4
4 l/h / 8 l/h
14 l/h
Conveying capacity 5
50 l/h
50 l/h
Viscosity range MaxPas
6
Max. 20
Max. 20
Operating temperature
range
50 °C – 195 °C
Over-temperature off switch
Hardware: Thermostat
Software: adjustable (max. 230 °C)
Temperature sensor
Unit: PT 100
External heating: switchable PT 100 / NI120/ NTC / FeCu
Control accuracy
+ / - 1 °C
Heating (unit)
2 heat zones, tank and
distribution block, difference
temp.
Heating (external)
(2 hoses + 2 heads)
(4 hoses + 4 heads)
(6 hoses + 6 heads)
(7 hoses + 7 heads)
(8 hoses + 8 heads)
1.
1
Pump type: Piston pump driven by compressed air.
2.
4
The melting power depends on the glue. (Provided with XP2505 at 150 °C)
3.
5
The conveying capacity depends on the glue. (Provided with XP2505 at 150 °C)
4.
6
The characteristics of the system performance depend on the viscosity of the glue.
5.
7
The conveying capacity depends on the pump that is used.
