UES perfectMelt - 2 Channel Board Connector Assignments

UES AG · Breuershofstr. 48 · 47807 Krefeld · Germany
Tel.: 0049-2151-72950 · Fax: 0049-2151-729578 · info@ues-ag.net · www.ues-ag.net
54
Connector CN2
PIN
DESCRIPTION
1
UES Connect
Out gun B
2
UES Connect
NEUTRAL (for out gun B)
3
UES Connect
PT100 gun B
4
UES Connect
NEUTRAL (for out hose B)
5
UES Connect
GND (for PT100 gun B)
6
UES Connect
Out hose B
7
UES Connect
GROUND
8
UES Connect
PT100 hose B
9
UES Connect
GND (for PT100 hose B)
10
UES Connect
Not connected
11
UES Connect
Out electrovalve 2+
12
UES Connect
Out electrovalve 2-
Connector CN4
PIN
DESCRIPTION
1
Alim-RS485
+8Volt
2
Alim-RS485
+RS485
3
Alim-RS485
-RS485
4
Alim-RS485
0Volt (GND)
Connector CN5
PIN
DESCRIPTION
1
Alim-RS485
+8Volt
2
Alim-RS485
+RS485
3
Alim-RS485
-RS485
4
Alim-RS485
0Volt (GND)
CN4 and CN5 have the same pin assignment.
Board 1 B → channel 1;
Board 1 A → channel 2.
Board 2 B → channel 3;
Board 2 A → channel 4.
