UES perfectMelt - Main Board Connector Assignments

UES AG · Breuershofstr. 48 · 47807 Krefeld · Germany
Tel.: 0049-2151-72950 · Fax: 0049-2151-729578 · info@ues-ag.net · www.ues-ag.net
47
Connector M7
PIN
DESCRIPTION
29
Digital OUT
Flashing lamp or generic OUT (OUT OP24Vdc)
30
Digital OUT
OPGND
Connector M8
PIN
DESCRIPTION
31
Digital Input
OP24Vdc rectified
32
Digital Input
ID5 Glue level sensor
33
Digital Input
ID4 No used now
34
Digital Input
ID3 No used now
35
Digital Input
ID2 Digital standby (Digital signal from mother machine)
36
Digital Input
ID1 Digital start (Digital signal from mother machine)
37
Digital Input
GND Opto Common Input ID (OP24VDC rectified)
Connector M9
PIN
DESCRIPTION
38
RS485-opto
OPGND
39
RS485-opto
- RS485-3 For external device (example SSP)
40
RS485-opto
+ RS485-3 For external device (example SSP)
41
RS485-opto
OP + 24Vdc
Connector CN4
I-Drive Connector (Rotary switch) (4 position)
Connector CN7
Tank Power Board connection (3 position) // Tank1 – Tank2 – 24Vdc rectified
Connector CN9
Hose and Gun Power Board connection (4 position) // OP8V RS485+ RS485- OPGND
Connector CN10
Piston pump input connection (4 position) // OP24V-ID sensor switch 1-ID sensor switch 2 -
OPGND
