UHP NETWORKS SCPC - Figure 18 Configuration of IP Route; Figure 19 Configuration of Additional Static IP Route

UHP SCPC MODEM
USER MANUAL, v3.2
© ROMANTIS 2015 18 www.uhp.net
Figure 18 Configuration of IP route
The Static route form allows adding static routes with the default gateway.
Figure 19 Configuration of additional static IP route
The following figures represent Routing tables of the Stations.
Terminal-1
Terminal-2
Route from Terminal-1 to Terminal 2
Route from Terminal-2 to Terminal 1
