UHP SCPC MODEM
USER MANUAL, v3.2
© ROMANTIS 2015 24 www.uhp.net
3. SCRIPT-BASED CONFIGURATION
UHP router can be configured with scripts which are sets of commands containing the device settings. Commands
are transmitted as a single block and then are sequentially performed in the device.
Script-based UHP router settings allow quick configuration of local and remote hardware. To configure the remote
hardware, a satellite connection to the remote device is required. The script is sent in a single block which ensures
execution of all transmitted commands of the script regardless of their order in the script.
Script can be created in the following WEB interface sections:
1. Select Setup via script in the Menu of commands;
A local device is configured in this section.
2. Maintenance –> Network script
The following can be configured in this section:
Local router;
Remote router with a specified serial number;
Group of remote routers.
Remote routers script-based configuration requires at least a one-way communication channel from the router
sending script to the routers which are being configured.
Scripts allow configuring the following router settings:
Network settings;
Modulator and demodulator settings;
Configuration profiles settings;
Router SW loading settings.
The full set and description of the commands for a configuration script is available via help command from the
console application when the device is accessed via a USB connection or Telnet protocol.
See below (Table 1) an example with a list of commands to configure the router located on Station-1 side using
configuration scripts.
Table 1 Example of commands included into configuration script
ip address 192.168.0.1 255.255.255.0 1
Assign an IP address to Ethernet interface
ip address 192.168.11.1 255.255.255.0 1
Assign an additional IP address to Ethernet interface
ip map 192.168.1.0 255.255.255.0 ml 1 1 0 1
Create a default route with LOW priority, via SVLAN 1, to the
Station-1, without applying Traffic shaper, VLAN 1
Permit to receive traffic from SVLAN 2
demodulator lnb power off
LNB, 13.5/18 VDC power is off
demodulator reference off
LNB 10 MHz reference signal is off
Transmit spectrum inversion is off
BUC 10 MHz reference signal is off;
Assign a local oscillator (LO) to LNB and BUC respectively
Create a SCPC modem profile with number 2 and automated run
profile 2 rx 11018170 834
Configure the receive frequency and symbol rate respectively
profile 2 tx 14317373 1667 8
Configure the transmit frequency and symbol rate respectively
Activation of TLC with local transmit and remote receive levels
Activation of ACM with max MODCOD=16APSK 3/4 and threshold
1 dB respectively
