Description
The battery pack is specially designed for B1 industrial protection level quadruped robot with capacity of 18000mAh,
nominal voltage of 58.8V, and charge and discharge management function. The battery pack uses high-performance
battery cells and advanced battery management system independently developed by Unitree Robotics to provide sufficient
power for B1 quadruped robot. Battery packs must be charged by using a special charger provided by Unitree Robotics.

Before using the battery pack for the first time, make sure that the battery packs are fully charged before using at the
first time!
Parts Name
[1] Power Switch
[2] LED Light
[3] Fastener
[4] Tab
[5] Charger Interface
[6] Foolproof Interface
[3]
[1]
[2]
[4]
[5]
[6]
