Vision 230/260/280 User Guide
22
-V 24V common supply for CANbus
L CAN low
PE Protective Earth
H CAN high
+V 24V power supply for CANbus
(Blk)
(Blu)
(Wht)
(Red)
-V
L
PE
H
+V
Figure 11. CANbus Connector
