Unitronics Vision 260 - Figure 13. Information Mode: Hardware Configuration

Vision 230/260/280 User Guide
28
Shows that an I/O on
Expansion Module
# 5 is short-circuited
Shows that I/Os on
Snap-in Module
are not short-circuited
X--no I/O Expansion
Module installed
Identical letters signify
identical I/O Expansion
Module types.
Figure 13. Information Mode: Hardware Configuration
