Universal Robots UR5 Service Manual

Figure 1
• Unscrew the 3 standoffs that hold the cover for the motherboard and mount the new larger
standoffs.
• Mount the motherboard onto the standoffs. Please note that the two screws toward the
outside of the controller may be more difficult to get into position.
Service Manual 61 UR5
5.Service and Replacement of parts
Copyright © 2009–2021 by UniversalRobotsA/S. All rights reserved.
