EDGE-3
Soundproof MDC O&M
Page 18
Installaon
Cable entry system
The cable entry system can be used at any of the cable entry points by removing the gland plate and adding the cable entry system
in its place.
Remove the gland plate by unscrewing the 2 m6
bolts and liing the panel away from the enclo-
sure. Keep somewhere safe if needing to put
back.
Remove the yellow tape cover from the cable
entry system foam.
Put cabling through and evenly distribute it along
the cable entry system to allow for the best seal-
ing.
Keep the cable entry foam together and feed it
through the gland hole and rmly press down on
the sides for a good seal.
