Installaon
Electrical Installaon.
The EDGE system is to be electrically installed in accordance with local and regional electrical codes.
Electrical supply to the EDGE System requires to be 100-130V or 200-240V 50/60 Hz from a 10A dedicated
branch circuit protected supply.
Electrical connecon to the EDGE system is made via the EMS located within the cabinet to an IEC 60320-1 C-14
fused appliance inlet.
**The Voltage range input is dependent on the Fan module conguraon. (Refer to model idencaon/rang
label & the voltage “INPUT” marking located on the rear panel of the EMS.
Rear panel of EMS showing Voltage congured for 200-240V
Input Voltage range 100-130V / 200-240V, 50/60Hz, 5A max (Voltage input model dependant)**
Fan Module Voltage Refer to EMS Rear panel & model Idencaon rang for conguraon
WARNING
The EDGE-3 equipment is congure for either 100-130V fans or 200-240V dependant on the fans ed, this
will be indicated to the rear of the EMS rang label. Reference image below.
The EDGE System requires a dedicated Power Source.
An approved power cord type to a maximum of 3m in length should be used to power the EDGE System to
ensure connued compliance.
Cables to be routed to avoid damage to the cables and prevent trip or other hazards.
