EDGE-3 DAX kit
The EDGE-3 DAX ‘Direcon Airow eXhaust’ kit is available to control the hot airow exhaust from the acve rear doors. Please see
data sheet for more informaon. Not available on 12U EDGE-3.
Remove the gland plate located at the top of the cabinet to the rear.
Keep the M6 xings safe as these will be required later.
Stage 1
Stage 2
Locate venlaon interface to rear of cabinet lid lining up entry holes in
both parts, ensuring that the gasket seals against lid edges.
Ret gland plate re-using M6 xings. Alternavely use the cable entry
system, which will also assist clamping down of the retrot venlaon
interface.
