2GM
1-6-11
7. Remove two screws at the back of the main PWB.
* When replacing the PWB with a new PWB, remove the EEPROM from the old PWB and mount it to the new PWB.
Figure 1-6-14 Removing the main PWB
Screws
Main PWB
EEPROM
