2GM
2-3-14
Connector Pin No. Signal I/O Description
YC3
Connected
to the main
PWB
YC4
Connected
to the main
motor
YC5
Connected
to the MP
feed clutch
YC6
Connected
to the
registration
clutch
YC7
Connected
to the bias
PWB
1 SGND - Ground
2 OVSYNK O OVSYNK signal
3 SGND - Ground
4 RSTN O RSTN signal
5 SGND - Ground
6 EGRN O EGRN signal
7 SDIR O SDIR signal
8 SBSY O SBSY signal
9 PDMASKN O PDMASKN signal
10 EGSI I EGSI signal
11 SCKN I SCKN signal
12 EGSO O EGSO signal
13 PLGCLK I PLGCLK signal
14 SGND - Ground
15 OUTPEN O OUTPEN signal
16 +5 V O 5 V DC power supply
17 +3.3 V O 3.3 V DC power supply
18 +3.3 V O 3.3 V DC power supply
19 SGND - Ground
20 SGND - Ground
1 FEDDRN O Feed clutch: On/Off
2 PFSEN I Paper feeder control signal
3 PFPER I Paper feeder control signal
4 PFCLK O Paper feeder control signal
5 PFMDRN O Paper feeder control signal
6 PGND - Ground
7 +5 V O 5 V DC power supply
8 MRDYN I Main motor ready signal
9 MOTORN O Main motor: On/Off
10 +24 V3 O 24 V DC power supply
1 +24 V3 O 24 V DC power supply
2 MPFDRN O MP feed clutch: On/Off
1 +24 V3 O 24 V DC power supply
2 REGDRN O Registration clutch: On/Off
1 HEATN O Heater lamp: On/Off
2 HVISEL O HVISEL signal
3 +5 V O 5 V DC power supply
4 SLEEPS O Sleep mode signal: On/Off
5 SLEEP24 O Sleep mode signal: On/Off
6 PSEL1 O PSEL1 signal
7 EXITN I Exit sensor: On/Off
8 MHVDR2 O Main charger grid bias voltage
9 ZCROSS I Zero-cross signal
10 HVCLK O HVCLK signal
11 +5 V O 5 V DC power supply
12 +5 V O 5 V DC power supply
13 +5 V O 5 V DC power supply
14 SGND - Ground
15 SGND - Ground
16 SGND - Ground
To Next Page
