Vacon 100 X Installation And Maintenance Manual

Safety vacon • 4
Service support: find your nearest Vacon service center at www.vacon.com
1
1.4 Warnings
VACON
®
100 X AC drive is meant for fixed installations (on the motor or on the wall)
only.
Only DVC A circuits (Decisive Voltage Class A, according to IEC 61800-5-1) are
allowed to be connected to the control unit. This advice aims to protect both the drive
and the client-application. VACON
®
is not responsible for direct or consequential
damages resulting from unsafe connections of external circuits to the drive. See para-
graph 1.6 for more details.
Do not perform any measurements when the AC drive is connected to the mains.
The touch current of VACON
®
100 X AC drives exceeds 3.5mA AC. According to stan-
dard EN61800-5-1, a reinforced protective ground connection must be ensured. See
paragraph 1.5 for more details.
If the AC drive is used as a part of a machine, the machine manufacturer is responsi-
ble for providing the machine with a supply disconnecting device (EN 60204-1). See
paragraph 4.1 for more details.
Only spare parts delivered by VACON
®
can be used.
At power-up or fault reset, the motor will start immediately if the start signal is
active, unless the pulse control for
Start/Stop logic has been selected ) and the STO inputs
are ready to be used (normal operation). The I/O functionalities (including start inputs)
may change if parameters, applications or software are changed. Disconnect, there-
fore, the motor if an unexpected start can cause danger. This is valid only if STO inputs
are energized. For prevention on unexpected restart, use appropriate safety relay con-
nected to the STO inputs.
The motor starts automatically after automatic fault reset if the autoreset function is
activated. See the Application Manual for more detailed information. This is valid only
if STO inputs are energized. For prevention on unexpected restart, use appropriate
safety relay connected to the STO inputs.
Before performing any measurement on the motor or on the motor cable, discon-
nect the motor cable from the AC drive.
Do not perform any voltage withstand test on any part of VACON
®
100 X. The tests
shall be performed according to a specific procedure. Ignoring this procedure may
damage the product.
Do not touch the components on the circuit boards. Static voltage discharge may
damage the components.
Check that the EMC level of the AC drive corresponds to the requirements of your
supply network. See paragraph 6.2 for more details.
In a domestic environment, this product may cause radio interference in which case
supplementary mitigation measures may be required.
