8. OPTIONS
The options available for VACON
®
100 X are described below.
8.1 Mains switch
The purpose of the Mains switch is to disconnect the VACON
®
100 X from the mains when, for ex-
ample, service actions are needed. The mains switch is available as option and it can be integrated
in the drive. The switch can be mounted on either side of the drive. See Figure 45.
Figure 45. The mains switch mounted on either side of the drive, MM4 example.
8.1.1 Installation
Figure 46. Disconnect the cable entry plate: example for MM5.
1
• Remove the cable entry plate from the drive on the left-hand-side if the mains
switch must be mounted on this side. Otherwise remove the cable entry plate
from the right-hand-side. See the Figure 46.
