Vacon NXP series User Manual

Descriptions of VACON® option boards vacon • 53
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
3
3.2 I/O Expander Boards OPTB_
• Option boards used for I/O expansion
• This board type can normally be plugged into slots B, C, D or E.
The number of control inputs and outputs on your VACON
®
AC drive can be increased with the I/O
Expander boards. This kind of boards can usually be placed in any board slot inside the AC drive
control unit except for slot A.
There are no board-related parameters for OPTB_ I/O expander boards (except for board OPTBB).
The boards you wish to have installed in your AC drive have to be defined in the type designation code
of the AC drive when ordering it from the factory.
Table 23. VACON
®
NX I/O Expander boards and their equipment
FC
type
I/O
board
Allowed
slots
DI AI TI AO DO RO Pt-100
42-240
VAC
input
Other
NXS
NXP
OPTB1 B,C,D,E (6) (6)
NXS
NXP
NXL
OPTB2 B,C,D,E 1 2
NXS
NXP
NXL
OPTB4 B,C,D,E
1
(iso-
lated);(mA)
2
(isolated
mA)
+24V/
EXT+24V
NXS
NXP
NXL
OPTB5 B,C,D,E 3
NXS
NXP
OPTB8 B,C,D,E 3
NXS
NXP
OPTB9 B,C,D,E 1 5
NXS
NXP
OPTB9 B,C,D,E
2
(enc)
NXS
NXP
OPTBB C
NXS
NXP
OPTBH B,C,D,E
DI = Digital input Pt-100 = Sensor input for Pt-100
AI = Analogue input AO = Analogue output
TI = Thermistor input RO = Relay output

Vacon NXP series Specifications

General

Communication interfaces	RS-485, Ethernet
Storage temperature range	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Product series	NXP
Voltage range	200 V to 690 V
Input voltage range	200 V to 690 V
Frequency range	0 Hz to 500 Hz
Control method	Vector control
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Enclosure classes	IP21, IP54
Braking chopper	Built-in or external
EMC filter	Built-in or external
Communication protocols	Modbus, Profibus, CANopen, Ethernet
Operating temperature range	-10°C to +50°C
Humidity range	5% to 95% (non-condensing)
Cooling method	Air-cooled or liquid-cooled
