Vacon NXP series User Manual

4
vacon • 82 VACON® Option Boards – operational details
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Table 47. VACON
®
option boards, type D
Adapter boards
NXOPTD_
OPTD1 DE 17457 System Bus adapter board: 2 x fiber optic pairs
OPTD2
7)
(B)DE 17458 System Bus adapter board: 1 x fiber optic pair & CAN bus adapter (galvanically decoupled)
OPTD3 DE 17459 RS232 adapter card (galvanically decoupled)
OPTD6 BDE 17462 MonitorBus adapter board (galvanically decoupled)
Explanations:
1)
Analogue inputs AI1 and AI2, analogue output AO1 and voltage reference +10Vref galvanically decou-
pled (all these in same potential)
2)
Analogue input AI1 and analogue outputs AO1 and AO2 galvanically decoupled from each other and
other electronics
3)
Similar to OPTA1 only with bigger terminals for 2.5mm
2
wires
4) Special application required for use in NXS
5) Bidirectional terminals
6)
In case of several optional slots, the bold slot letter indicates the factory default slot (NOTE: not appli-
cable if several boards with the same default slot are installed)
7)
If the board is placed in slot B the SystemBus is not available; only the Monitor Bus can be used.
Remove jumpers X5 and X6.
8) AI1 0-10V, AI2 -10V...+10V
9) AO1 mA, AO2 V
10) 2 (mA/V), incl. -10…+10V
11) Also -10V ref

Vacon NXP series Specifications

General

Communication interfaces	RS-485, Ethernet
Storage temperature range	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Product series	NXP
Voltage range	200 V to 690 V
Input voltage range	200 V to 690 V
Frequency range	0 Hz to 500 Hz
Control method	Vector control
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Enclosure classes	IP21, IP54
Braking chopper	Built-in or external
EMC filter	Built-in or external
Communication protocols	Modbus, Profibus, CANopen, Ethernet
Operating temperature range	-10°C to +50°C
Humidity range	5% to 95% (non-condensing)
Cooling method	Air-cooled or liquid-cooled
