2.5.2 Drive sizes FI9-FI14
The inverter unit section (IUS) includes the largest NXI drives from the VACON
®
product family. The
inverter units are all Vacon’s premium NXP dirves.
As standard the IUS section includes the following (see Figure 7):
1. Input fuses (DC fuses)
2. The NXI drive
3. Service platform/module removal
4. Control section and fixed external terminals, 70 pcs
As pre-engineered standard options we can provide the following:
• dU/dt (+ODU)
• Common mode filter (+OCM)
• Input Switch with charging (+ISC)
•Arc detection (+ADU)
• Motor fan control (+AMF)
• Motor heater feeder (+AMH)
• Mechanical break control (+AMB)
•Top cabling (+COT)
• UL approved design and components (+NAR)
• Cabinet heater (+ACH)
•Cabinet light (+ACL)
Table 10. Available IUS section sizes FI9-FI14
IUS type Drive size Width x Height x Depth (mm)
Width x Height x Depth (mm),
with +ODU
IUS_9 FI9 800 x 2100 x 605 800 x 2100 x 605
IUS_9_2x FI9 1200 x 2100 x 605 1200 x 2100 x 605
IUS_10 FI10 800 x 2100 x 605 800 x 2100 x 605
IUS_10_2x FI10 1200 x 2100 x 605 1200 x 2100 x 605
IUS_12 FI12 1000 x 2100 x 605 1000 x 2100 x 605
IUS_12_2x FI12 1800 x 2100 x 605 Not available
IUS_13 FI13 1400 x 2100 x 605 1400 x 2100 x 605
IUS_14 FI14 2800 x 2100 x 605 2800 x 2100 x 605
