1
vacon • 6 Introduction
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
1.4 Project specifications
1.4.1 Parameters
Project parameters are selected with the line-up configuration tool.
Table 3. Example of parameters selected from the configuration tool
Parameter Selection
Mains network type IT
Mains voltage
690 V
AC
Frequency 50 Hz
Mains maximum current 2500 A
Busbar system DC+, DC-, PE
Busbar system voltage
1100 V
DC
Busbar system maximum current 2500 A
I
cw
, 1 s
50 kA
PE design 50%
Busbars and flexibars Tinned
Cabinet type Rittal TS8
Height 2000 mm
Depth 600 mm
Cabinet material Powder coated steel
Sheet steel parts within the enclosure Without coating
Colour RAL 7035
Ingress protection of enclosure Protection against accidental touching of live parts
Protection barriers and covers IP 21
Ambient temperature 35°C
Halogen free wires and ducts No
Mimic diagram No
Type of packing Sea freight box
Application Industry
