Vaillant TURBOmax Plus SERIES User Manual

5
LIST OF CONTENTS
Contents included with
boiler (THERMOcompact)
Ensure that all contents are included
before commencing installation.
BEDIENUNGSANLEITUNG
BEDIENUNGSANLEITUNG
BEDIENUNGSANLEITUNG
BEDIENUNGSANLEITUNG
9
10
10
10
BEDIENUNGSANLEITUNG
Instructions for Installation
8
11
7
1
6
5
2
V
R
C
-V
C
C
o
0
I
C
o
3
4
Fig. L.2: Items supplied with unit (THERMOcompact)
Table L.2: Items supplied with unit (THERMOcompact) * for THERMOcompact 624/628 only
Euro B/S_VC_025/0
DO NOT remove the boiler from the
polystrene base at this stage.
Item Quantity Description
1 1 Boiler
2 1 Flue restriction ring
3 1 Controls cover door
6 3 Copper tails for gas and water pipework
4 1 Lower cover plate (packed in bottom packaging)
7 1 Template
8 2 Guarantee Card and Benchmark log book
9 1
Installation and connection accessories and
PRV packages
11 1 Hanging bracket
5 3 Flow and return service value, gas service valve
THERMOcompact
10 3
Installation and Servicing, Users and Flue Installation
Instructions

Vaillant TURBOmax Plus SERIES Specifications

General

Category	Boiler
Modulation	Yes
Model	TURBOmax Plus SERIES
Fuel type	Natural gas
Mounting	Wall-mounted
Heating Circuit	Single
Output	24kW, 28kW
Warranty	2 years (extendable)
