5. Configuring analog outputs
5.1 Analog output configuration overview
The transmitter has 3 analog outputs that can be configured with the Insight PC software.
Each output has the same set of configuration options in the analog output 1 — 3 menus under
the Configure Device menu (Analog output 1 shown in example).
The available selections depend on the probe that is connected to the transmitter
(for example, CO
2
output parameter selection is only available for CO
2
probes).
Figure 14 Analog output configuration options example
The Analog output type selection in the General menu defines whether the
outputs are used for voltage or current output.
