9. Technical data
9.1 Specifications
Table 6 Indigo-compatible probes
Measurement type Probe models
Humidity and temperature HMP1, HMP3, HMP4, HMP5, HMP7, HMP8, HMP9
Temperature TMP1
Dew point DMP5, DMP6, DMP7, DMP8
Carbon dioxide GMP251, GMP252
Vaporized hydrogen peroxide HPP271, HPP272
Moisture in oil MMP8
Table 7 Indigo201 inputs and outputs
Property Description/value
Insight PC software configuration access
1)
USB-C port on transmitter (compatible with
generic USB cables)
Power supply input
15 … 30 V DC
2)
24 V AC ±10 % 50/60 Hz
Relay contacts x 2 Max. switching power 30 W
Max. switching current 1 A
Max. switching voltage 40 V DC / 28 V AC
Three analog outputs (voltage or current) Voltage: 0 … 1 V, 0 … 5 V, 0 … 10 V, 1 … 5 V,
scalable, min. load 1 kΩ
Current: 4 … 20 mA, 0 … 20 mA, scalable, max.
load 500 Ω
Accuracy of analog outputs at 20 °C ±0.1 % full scale for 0 … 10 V and 0 … 20 mA
1) Vaisala Insight software for Windows® available at www.vaisala.com/insight.
2) When used with the HMP7 probe, the minimum required power supply input is 18 V DC.
Indigo201 User Guide M212842EN-B
50
