Examples (ASCII and NMEA 0183, device address 0):
You need a 20-second averaging time for wind speed and direction both
in wind data and composite data message in every 60 seconds. Wind
speed is in knots and wind direction offset +10°.
Changing the measurement interval to 60 seconds:
0WU,I=60<cr><lf>
0WU,I=60<cr><lf>
Changing the averaging time to 20 seconds, the wind speed unit to
knots, and direction offset to +10°:
0WU,A=20,U=N,D=10<cr><lf>
0WU,A=20,U=N,D=10<cr><lf>
Changing the wind parameter selection:
0WU,R=0100100001001000<cr><lf>
0WU,R=01001000&00100100<cr><lf>
NOTE
Several parameters can be changed with the same command as long as
the command length does not exceed 32 characters, see below.
NOTE
Character '&' is not allowed in the command.
