Motor protection relay
Operation and Configuration
VAMP 150
VM150.EN005 Vamp 24h support phone : +358 (0)20 753 3264
27
7. Selection of the communication protocol and setting of the
communication parameters (COM menu), see Chapter 5.8.
8. Other required parameters, for example the DI input, mA
output and circuit-breaker failure protection.
7.1.2. Configuration examples
The following example illustrates the calculation and scaling of
seting values and the grouping of output relays in a typical
protection configuration. The numerical values given in the
example are to be regarded as guidelines only.
Example:
The example is based on the technical application drawing of
Chapter 3, Figure 3.1-1. in the technical description.
In the application the following functions and stages are used:
• Two-stage overcurrent protection (I>, t> and I>>, t>>)
• Stall protection Ist> (Ist>, ImotSt, Type, tDT>)
• Overload protection (T>, Alarm, Tau, Tau2, Imax40,
Imax70, Tamb)
• Two-stage residual current protection (Io>, to>and Io>>,
t>>)
• Frequent start protection N> (Sts/h, Interval)
The above functions are enabled via the ENABLE menu by
selecting the "On" in the ENABLE menu, see Chapter 5.2. the
functions not to be included are disabled by selecting the “Off”
value.
1 Output data:
Give within the parenthesis are the configuration menus where
the settings are done.
Transforming ratios of measurement transformers
Motor niminal current Imot 400 A
Current transformer (CT) CTprim 500 A
(SCALING/IL Scale) CTsec 5 A
Residual current transformer (CTo)
(SCALING/Io Scale)
CToprim
CTosec
Ioinp
100 A
1 A
1 A
