VAMP 150 - Arc Option Card; Connectors; Tests and Environmental Conditions; Disturbance Tests (en 50263)

VAMP Ltd
Motor protection relay
Technical Description
VAMP 150
VM150.EN005 Vamp 24h support phone : +358 (0)20 753 3264
41
5.1.9. Arc option card
Binary input
- operationg voltage +48 Vdc (optically isolated input)
Binary output
- output voltage level +48 Vdc (transistor controlled output)
Arc sensor inputs
- number of inputs
- operating voltage level
- current consumption
passive state
active state (light act.)
2
12 Vdc (optically isolated inputs)
∼ 20 mA
∼ 2 mA
∼ 20 mA
5.1.10. Connectors
Connector X1
Max. torque 1.2 Nm
AWG 14 - 10
Connectors X2 and X4
Max. torque 0.5 – 0.6 Nm
AWG 24 - 12
5.2. Tests and environmental conditions
5.2.1. Disturbance tests (EN 50263)
Emission
- Conducted (EN 55022) 0.15 - 30 MHz
- Emitted (EN 55022) 30 - 1 000 MHz
Immunity
- Static discharge (ESD) EN 61000-4-2, class III
6 kV contact discharge
8 kV air discharge
- Fast transients (EFT) EN 61000-4-4, class III
2 kV, 5/50 ns, 5 kHz, +/-
- Surge EN 61000-4-5, class III
1 kV, 1.2/50 µs, common mode
2 kV, 1.2/50 µs, differential mode
- Conducted RF field EN 61000-4-6
0.15 - 80 MHz, 10 V/m, 80% AM (1 kHz)
- Emitted RF field EN 61000-4-3
80 - 1000 MHz, 10 V/m, 80% AM (1 kHz)
- GSM test EN 61000-4-3
900 MHz, 10 V/m, pulse modulated
1 MHz burst IEC 60255-22-1
1 kV, differential mode
2,5 kV, common mode
Voltage interruption IEC 60255-11
