DI to block AR setting
This setting is useful with an external synchro-check device.
This setting only affects re-closing the CB. Re-closing can be
blocked with a digital input, virtual input or virtual output.
When the blocking input is active, CB won’t be closed until the
blocking input becomes inactive again. When blocking becomes
inactive the CB will be controlled close immediately.
Setting parameters of AR function:
Parameter Value Unit Default Description
ARena ARon; ARoff - ARon
Enabling/disabling the
autoreclose
Block None,
any digital
input,
virtual input
or virtual
output
- -
The digital input for block
information. This can be used,
for example, for Synchrocheck.
AR_DI None,
any digital
input,
virtual input
or virtual
output
- -
The digital input for toggling
the ARena parameter
AR2grp ARon; ARoff - ARon
Enabling/disabling the
autoreclose for group 2
ReclT 0.02 … 300.00 s 10.00
Reclaim time setting. This is
common for all the shots.
ARreq On; Off - Off AR request event
ShotS On; Off - Off AR shot start event
ARlock On; Off - Off AR locked event
CritAr On; Off - Off AR critical signal event
ARrun On; Off - Off AR running event
FinTrp On; Off - Off AR final trip event
ReqEnd On; Off - Off AR end of request event
ShtEnd On; Off - Off AR end of shot event
CriEnd On; Off - Off AR end of critical signal event
ARUnl On; Off - Off AR release event
ARStop On; Off - Off AR stopped event
FTrEnd On; Off - Off AR final trip ready event
ARon On; Off - Off AR enabled event
ARoff On; Off - Off AR disabled event
CRITri On; Off - On AR critical final trip on event
AR1Tri On; Off - On AR AR1 final trip on event
AR2Tri On; Off - On AR AR2 final trip on event
CRITri On; Off - On AR critical final trip off event
AR1Tri On; Off - On AR AR1 final trip off event
AR2Tri On; Off - On AR AR2 final trip off event
