VarioCooking Center 211 - Page 126

Calibration
Calibration log
Troubleshooting errors during the allocation process
Error code Explanation Troubleshooting
Error-40 The read temperature values
are too high. Same conditions
as for displaying service mes-
sages.
●BadcontactfromthermocoupletoPCB
●Brokenthermocouple
●PCBboardmalfunction
Error-38 Time limit reached without rec-
ognition of boiling.
(T° core probe < 80°C
or core probe temperature vari-
ation > 0.1 ° C)
●
Electricalpower>Missingphase?SSRfault?
SSRcommand?SSRmalfunction?
●Fault with a thermocouple or the correspond-
ing board
●Energy optimisation system active
(Sicotronic)
●
Faultwithoneormoreheater(s),badwiring?
●Coreprobefullysubmerged?
Error-36 At least one thermocouple
temperature measured
> 200°C
●Waterpresent?
●Broken thermocouple
●PCB board malfunction
●SSR malfunction
Error-33 Heating zone calibration result
outside tolerances [200; 6000]
●Check which thermocouple:
Service mode > diagnosis > Real time data
●Check the thermocouple for good contact
with pan bottom
●Check the centring of the thermocouple
●Thermocouple or corresponding PCB mal-
function
●For pressure units only:
Check for correct function of the pressure
sensor?Pressurecircuitblocked?
Error-32 At least one point of the left
core probe is outside given
tolerance [-3°C; +3°C]
●Enoughwaterpresent?
●Coreprobefullysubmerged?
●Altitudesetting?
●For pressure units only:
Check for correct function of the pressure
sensor?Pressurecircuitblocked?
●Thermocouple or corresponding PCB mal-
function
IX.20
v03 • July-2016 • Hen
Heating system module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxXH1009xxxxxxx
