Description of the 3 stages of the process
Preconditions
Preconditions
Purpose: Check that all the conditions for starting the cooking mode are met.
Step Note Safety
A
Reference pressure
Cover must be in the up and
unlocked position
L: S10 = 1
R.: S12 = 1
B
Starting pressure mode
Core probe (L: B12 / R: B13) and pan ther-
mocouple (L: B1 / R: B2) must not be faulty.
C
Cover lock
Cover must be detected in the down
position
L: S11 = 1
R: S13 = 1
D
Cover must be locked
VCC112P, L: S7 = 1
VCC112P, R: S19 = 1
VCC211/311: S7 + S21 = 1
One of the safety features of the pressure mode is also based on the measurement of temperatures
in the cooking area. Always check the proper setting of the altitude of the installation of the unit.
The theoretical boiling temperature is inferred from this setting!
XI.10
v03 • July-2016 • Hen
Pressure Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
112P, 211P, 311P ExxPH1009xxxxxxx 01-01-00
