Description of the 3 stages of the process
Preheating
1. Preheating
Purpose: Evacuate the cold air from the pan, replace it by hot steam.
Step
Note Safety
A
Preheating
Decompression valve (L: Y4 R: Y5) is open
Control box solenoid valve Y2 is active as
long as P > 4mbar (L:P1 / R: P2)
Unlocking is prohibited as soon as P > 25
(L:P1 / R: P2) mbar or T°c > (T°c boiling -
20°C)* (L:B1 / R: B2)
Pressure switch maximum pressure: 200 mbar (L:F7 / R) F11)
cut off the appliance via K1
Pressure switch 20 mbar (L: F12 / R: F13) does not allow
unlocking while P > 20 mbar
B
Security release Prevent unlocking the unit
Unauthorised unlock if:
P > 25 mbar (L: P1 / R: P2)
or T°c > [T°c boiling - 20°C], (L: B12 + B1 / R: B13 + B2),
C
Preheating safety device
Avoids malfunction due to a clogged pres-
sure measuring circuit
End pressure mode if:
T°c > [T° boiling + 7°C], (L: B12 + B1 R: B13 + B2),
and P** unchanged *, (L:P1 / R: P2)
D
Go to next step
(regulation)
Under temperature** or pressure**
conditions.
* Different values depending on the model.
**Valuesarenotspeciedforthesakeofcondentiality.
XI.11
v03 • July-2016 • Hen
Pressure Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
112P, 211P, 311P ExxPH1009xxxxxxx 01-01-00
