100 series
100 to 128
Num. Compo-
nent
Conditions Diagnosis
100
B12.1 to
B12.6
Temperature measured >
300°C
●
Check the connection of the thermocouple to the board
● Exchange the thermocouple if necessary
● If necessary exchange the corresponding board
If the temperature measured is -30°C (-22°F) this
indicates that the device needs allocation
●
After a thermocouple or a board is exchanged it may
be necessary to carry out another allocation, or a
calibration of the unit.
101
B13.1 to
B13.6
Temperature measured >
300°C
110
B1
Temperature measured >
655°C = Err.
111
B2
Temperature measured >
655°C = Err.
120
PCB A2
Temperature measured >
80°C
121
B4
Temperature measured >
655°C = Err.
122
B5
123
B6
124
B7
125
B8
126
B9
127
B10
128
B11
129
B14
130
B15
131
B16
132
B17
XIII.04
v03 • July-2016 • Hen
Service message module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxXH1009xxxxxxx 01-00-08
