Description of the Service Mode
Diagnosis, sensors
Left hydraulic system
Probe Use Unit
VarioDose
Solenoid valve Y1 All
Cold water
Solenoid valve Y6 All (hot water
option)
Hot water
Solenoid valve Y7 All (hot water
option)
Columns displayed
Name Explanation Details
Status
Status of the solenoid valve ●Open or closed
Volume
Amount of water counted since the
last power up
IV.09
v03 • July-2016 • Hen
Service Mode Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxXH1009xxxxxxx 01-00-08
