Schematic diagram
VarioCooking Center
©
112P, up to index H
Left pan Description Right pan
Y1 Solenoid valve pan lling Y3
Y2 Solenoid valve control box Y2
Y4 Solenoid valve pressure release Y5
B1 Pan thermocouple B2
R1 - R3 Pan heating zone R4 - R6
B4 - B6 Heating zone thermocouple B7 - B9
B12.1 - B12.6 Core sensor thermocouple B13.1 - B13.6
F6 Safety thermostat 205°C F10
F7 High-pressure switch 20kPa (200mbar) F11
F12 Pressure switch 2.0kPa (20 mbar) F13
F17 - F19 Safety thermostat 355°C heating zone F20 - F22
F25 Safety thermostat VarioDose 130°C F26
P1 Pressure sensor P2
PT 1 Pan position potentiometer PT 2
M2 Pan tilting actuator M6
M3 AutoLift actuator M7
M4 Cover lock actuator M8
M5 Pan valve motor M9
S6 Limit switch, lid unlocked S18
S7 Limit switch, lid locked S19
S8 Pan valve position microswitch S20
S10 Limit switch, top lid position S12
S11 Limit switch, bottom lid position S13
v03 • July-2016 • Hen
VI.03
Control Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
112, 112P E11XH1009xxxxxxx
