Schematic diagram
VarioCooking Center
©
211, 311
Left pan Description
Y1 Solenoid valve pan lling
Y2 Solenoid valve control box
Y4 Solenoid valve pressure release
B1 Pan thermocouple
R1 - R8 Pan heating zone
B4 - B11 Heating zone thermocouple
B12.1 - B12.6 Core sensor thermocouple
F6 Safety thermostat 215°C
F7 High-pressure switch 20kPa (200mbar)
F12 Pressure switch 2.0kPa (20 mbar)
F17 - F24 Safety thermostat 355°C heating zone
F25 Safety thermostat VarioDose 130°C
P1 Pressure sensor
PT 1 Pan position potentiometer
PT 2 Lid position Potentiometer
M2 Pan tilting actuator
M3 Lid tilting actuator
M4 Lid locking actuator
M5 Pan valve motor
S6 Limit switch, lid unlocked
S7 + S21 Limit switch, lid locked
S8 Pan valve position microswitch
v03 • July-2016 • Hen
VI.11
Control Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
211, 311
211P, 311P
E21VH1009xxxxxxx, E21PH11009xxxxxxx
E31VH1110xxxxxxx, E31PH11009xxxxxxx
