Installation, Operating & Maintenance Instructions
Series 650 DN 100-250 (I.D. 4“ - 10”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
280672EB
2010-12-15
40/94
for Slave valve
Command: s:1012000000<CR><LF>
Answer: s:10<CR><LF>
Description: Address allocation for Slave valve #18 (12
hex
).
Screenshot:
• Address allocation:
Each valve connected to the valve cluster system must have its unique cluster address. It is possible to address
255 cluster valves. The address allocation is as follows:
Master valve: 00
Slave valves: 01 – FE
hex
Note: The device address information must be configured when setting up the valve cluster. It is stored in a power
save memory and therefore will be kept even the valve is disconnected from power.
