VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION B-18: REAR SHOCK
Preparations:
Disassemble Left Side Body Panel see Section B-12
Unscrew the nut #1 by using a open wrench 14mm
Unscrew the bolt #2 by using a open wrench 13mm
Unscrew the bolt #3 by using a open wrench 12mm and
remove rear shock
Remark:
For disassembling of the rear shock it is not necessary
to remove the motor and the side cover
All parts of removed rear shock
Tighten the bolts and the nut according to the required torque, see Section F-4
