Vectrix VX-2 - Handlebar-Right Switch Assembly

VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION C-5: HANDLEBAR-RIGHT SWITCH ASSEMBLY
Preparations:
Remove Front Console Cover (for VIN all LYSE and LYSV40002B1000001 to
LYSV40002B1000034) see Section B-2
Remove Vertical Panel Cover-Lower (for ICM access for VIN all LYSE and LYSV40002B1000001
to LYSV40002B1000034) see Section B-4
Remove all cable strips
Open connector CN3 from the Interface Control Module
(ICM)
Additional information see Section 1 of F-1
Unscrew the PH2 Phillips screw
Unscrew the PH2 Phillips screw
Remove the Right Switch assembly
Test functions of Right Switch assembly
