Vectrix VX-2 - Section E-2: Malfunctions

VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION E-2: MALFUNCTIONS
- No Top Speed
- Check setting of the controller
- Check correct function of the throttle, adjust or exchange if needed
- No function and no indication on Speedometer
- Check Fuse 1 (15A) of the converter
- Check voltage on Controller power in line (red and black thick wire) should be
higher than 36 V.
- Converter broken
- Full function but no indication on Speedometer
- Check connection of the speedometer
- Speedometer broken
- No indication of the energy bar on Speedometer
- Check Voltage of the battery
- Check Voltage on Pin 1 of the speedometer connector. Should be the battery
Voltage
- Speedometer or controller broken or wire between controller and speedometer
- No indication of the consumption bar on Speedometer
- Check Voltage of the battery
- Check Voltage on pin 1 of the Speedometer connector. Should be the battery
Voltage
- Speedometer or Controller broken or wire between Controller and Speedometer
- No change of battery voltage and mph/kph on Speedometer
- Check correct function of MODE switch
- Mode switch or Speedometer broken
- No indication of speed on Speedometer but motor running is okay
- Check if the Voltage on Pin 5 of the speedometer connector. Should change if
Motor is turned by hand.
Speedometer or Controller broken or wire between Controller and Speedometer
