Vectrix VX-2 - Handlebar-Left Switch Assembly

VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION C-4: HANDLEBAR-LEFT SWITCH ASSEMBLY
Preparations:
Remove Front Console Cover (for VIN all LYSE and LYSV40002B1000001 to
LYSV40002B1000034) see Section B-2
Remove Vertical Panel Cover-Lower (for ICM access for VIN all LYSE and LYSV40002B1000001
to LYSV40002B1000034) see Section B-4
Remove all cable strips
Open connector CN1 from the Interface Control Module
(ICM)
Additional information see Section 1 of F-1
Unscrew the PH2 Phillips screw
Unscrew the PH2 Phillips screw
Remove the Left Switch assembly
Test functions of Left Switch assembly
