VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION C-3: BRAKE SWITCH
(Both Left and Right)
Preparations:
Remove Front Console Cover (for VIN all LYSE and LYSV40002B1000001 to
LYSV40002B1000034) see Section B-2
Remove Vertical Panel Cover-Lower (for ICM access for VIN all LYSE and LYSV40002B1000001
to LYSV40002B1000034) see Section B-4
Remove all cable ties (1)
Remove connector from the Interface Control Module
(ICM)
Disconnect both wires at the brake switch connector and
twist out (by hand) the brake switch at the brass coupling
Test functions of Brake Switch assembly
