VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION B-20: HANDLEBAR
Preparations:
Disassemble Front Console Cover see Section B-2
Disassemble Front Vertical Panel-Lower see Section B-4
Disassemble Front Vertical Panel-Upper see Section B-5
Open the connector from the Speedometer
Remove the two cross screws by using a Phillips
screwdriver #2 and remove the complete Speedometer
cover
Remove all parts of the handlebar
- Left- and right switch assembly
- Left- and right brake handle assembly
- Throttle
- Hand grips + Handlebar weights
Unscrew the nut #2 by using a open wrench 13mm
Unscrew the bolt #1 by using a open wrench 13mm and
remove the bolt
Tighten the bolts and the nut according to the required torque, see Section F-4
1
2
