VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION C-13: REAR TURN INDICATOR LIGHT ASSEMBLY
Remove all cable ties
Open 2-pin connector
Cut the cable of the Rear Indicator Light assembly
Remark: Connector has to be cut because the
connector doesn’t fit through the hole of
the plastic
Remove the nut with an open wrench 14mm
Pull out the Rear Turn Indicator assembly
Replace entire Rear Turn Indicator Assembly
Note: The Rear Turn Indicator Assembly is LED so you
must replace the entire assembly.
Remark: Slightly push in the pins into the new
connector. Be sure of the right position.
Refer to the old connector
Test functions of Rear Turn Indicators
