VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
SECTION C-1: SPEEDOMETER
Preparations:
Disassemble Front Console Cover see Section B-2
Disassemble Speedometer Cover see Section B-3
Unscrew both nuts with 8mm open wrench
Remove the plastic bracket
Remark: On the underside of the plastic bracket there
are two plastic attachment points which fit into
two holes of the plastic cover. These
attachment points fixed the Speedometer in the
right position.
Carefully remove the Speedometer from the plastic cover
Test functions of speedometer
