VECTRIX VX-2 SERVICE MANUAL
Version 1.0/July 2011
VECTRIX, LLC
Note: After disconnecting Battery #3, use electrical tape
to insulate the loose terminal end from Battery #4
Lift up the Middle Battery (#2) as shown and remove it.
Each battery typically weighs XXXX pounds/XXXX kg.
Remark:
Batteries are fixed to the battery case with strong Velcro.
Move the batteries sideways to loosen them from the
Velcro before removal.
Lift up Front Battery (#1) as shown and remove it
Lift up Middle Rear Battery (#3) as shown and remove it
