6 Set up with the display and adjustment module
VEGAPULS 64 • Two-wire 4 … 20 mA/HART
51141-EN-210219
Inthismenuitemyoucandenethewaymeasuredvaluesareindi-
cated on the display.
The default setting for the displayed value is " Distance".
Inthismenuitemyoudenethenumberofdecimalpositionswith
which the measured value is displayed.
The default setting for the display format is " Automatic".
The display and adjustment module has a backlight for the display. In
thismenuitemyoucanswitchthelightingonoro.Youcanndthe
required operating voltage in chapter " Technical data".
To maintain the function of the device, the lighting is temporarily
switchedoifthepowersupplyisinsucient.
In delivery status, the lighting is switched on.
In this menu item, the device status is displayed.
The min. and max. measured value, the measurement reliability as
well as the min. and max. electronics temperature are stored in the
sensor. The values are displayed in menu item " Peak value" or "
Further peak values".
A reset menu is opened with the [OK] key in the respective peak
value window:
With the [OK] key in the reset menu, the peak values are reset to the
current measured value.
The " Echo curve" shows the signal strength of the echoes over the
measuring range in dB. The signal strength enables an evaluation of
the quality of the measurement.
Display - Displayed value
1 and 2
Display - Display format
Display - Backlight
Diagnostics - Device
status
Diagnosis - Peak value
Diagnosis - Curve indica-
tion
